Julabo F32-MA Refrigerated Heating Circulator -35C to 200C 8L 110V / 9A
MULTI-DISPLAY (LED) for actual and setpoint values, warning/safety functions and pump stage Keypad for setpoints, warning/safety values and menu functions PID2 temperature control with drift compensation ATC3 3-Point-Calibration
Early warning system for low liquid level (DBGM 203 06 059.8) Adjustable high temperature cut-out, visible via display RS232 interface for online communication SMART PUMP electronically adjustable pump stages Active Cooling Control
Technical Data
JULABO F32-MA (TopTech refrigerated/heating circulator)
Temperature
| Working range | −35 to +200 °C |
| Stability | ±0.02 °C |
| Control | PID |
| Display | LED, 0.01 °C (−9.99…99.99) / 0.1 °C outside that |
| Ambient | +5 to +40 °C |
Heating and cooling
| Heating | 1 kW at 115 V |
| Cooling (ethanol) | 0.45 kW at +20 °C |
| 0.39 kW at 0 °C | |
| 0.15 kW at −20 °C | |
| 0.06 kW at −30 °C | |
| Refrigerant | R134a (air-cooled compressor) |
Pump
| Flow | 11–16 L/min (4 stages) |
| Pressure | 0.23–0.45 bar (3.3–6.5 psi) |
| Connections | M10×1 |
| Barbed fittings | 8 / 10 mm ID |
Bath and size
| Bath opening (W × L) | 18 × 12 cm |
| Bath depth | 15 cm |
| Fill volume | 5.5–8 L |
| Dimensions (W × L × H) | 31 × 42 × 64 cm |
| Weight | 37 kg (about 81 lb) |
Other
- DIN 12876-1: Class III (FL)
- Interface: RS232 (Profibus optional)
Julabo F32-MA Refrigerated Heating Circulator -35C to 200C 8L 110V / /9A
- Brand: Julabo
- Product Code:JF32-MA
- Availability:In Stock
-
US$ USDT 1,812.49
